    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation

    Ask Lasest Price
    Brand Name : BETTER
    Certification : CE ISO9001
    Price : $6,800.00/pieces 2-2 pieces
    • Product Details
    • Company Profile

    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation

    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Tips:
    If you can't find the model you need or don't know which one you need, please send us an inquiry for details
    Click to contact us>>
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Product Description
    YW series Dissolved Air Floatation is mainly for solid-liquid or liquid-liquid separation.
    Large sum of micro bubbles produced by dissolving and releasing system adhere to solid or liquid particles with same density as waste water to make the whole float to the surface thus achieve the aim of solid-liquid or liquid-liquid separation.
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Model
    Capacity(m3/h)
    YW-5
    4-5
    YW-10
    8-10
    YW-50
    40-50
    YW-150
    120-150
    YW-300
    280-300
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Features
    (1) Large capacity, high efficiency and small occupying space.
    (2) Compact structure, easy operation and maintenance.
    (3) Silt expansion elimination.
    • Features

    (4) Aerate to the water while air floating, it has an obvious effect to the elimination of active agent and foul smell in water.
    Meanwhile, the increased dissolved oxygen provides a favorable condition to the follow-up process.
    (5) It can achieve the best effect in adopting this method when disposing the water with lower temperature, lower turbidity and
    more algae.Suitable area:
    slaughtering, starch, printing and dyeing, leather and tannery, petrochemical industry, domestic wastewater, etc.
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Model
    Length (mm)

    Width(mm)
    Height(mm)
    YW-5
    3300
    1800
    2000
    YW-50
    7000
    2600
    2400
    YW-100
    10000
    2800
    2600
    YW-150
    13500
    2800
    2600
    YW-300
    19200
    3400
    2800

    (1) Remove oil and TSS.
    (2) Separate small particles and algae in groundwater.
    (3) Recover valuable products in industrial sewage such as paper pulp.
    (4) Act as secondary sedimentation tank to separate and concentrate suspended particles and sludge.
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Main Products
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Project Case
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Certifications
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Company Profile
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Product Process
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
    Packing&Shipping
    Pure Water Treatment System for Microbubble Adsorption Sewage Solid Liquid Separation
