Rotary Drum Micro Filter for Industrial Wastewater Filtration Capacity of 5-500cbm/hr

Ask Lasest Price
Brand Name :	BETTER
Supply Ability :	100 Set/Sets per Month Micro Drum Filter for Industrial Wastewater filtration
Price :	$4,500.00/sets 1-1 sets

Add to Cart

Product Details
Company Profile

Rotary Drum Micro Filter for Industrial Wastewater Filtration Capacity of 5-500cbm/hr

Product Description

Drum filter/Microfiltration machine is a mesh filter that traps small suspended solids. It has a drum-shaped metal frame. The drum
rotates around a horizontal axis and is supported by stainless steel (or copper wire or synthetic) filaments network. It can be
used to filter raw water from waterworks and remove algae, leeches and other plankton. It can also be used for filtration
treatment of industrial water, recovery of swimming materials in industrial wastewater, and final treatment of sewage.
The microfiltration machine is a 80-200 mesh/in2 microporous screen fixed to a rotary drum type filter device, and intercepts the
solid particles in the aquaculture water to achieve a solid-liquid separation purification device. At the same time as filtering,
the microporous screen can be cleaned in time by rotating the drum and recoil the force of the water. Keep the device in good
working condition at all times. Our company's microfiltration machine is one of the best technology for the treatment of seawater
recirculating water aquaculture, aiming at the problems that the existing microfiltration machine is easy to be blocked, easily
damaged, easily corroded and difficult to maintain. The product is used to purify the water body through the separation of the
solid waste in the aquaculture water to achieve the purpose of recycling.

Working principle

The working principle of the microfiltration machine is that when the aquaculture water passes through the microporous screen on the
microfiltration drum, the solid waste in the aquaculture water body is separated under the rotating action of the rotating drum,
so that the water body is purified and recycled. At the same time as filtering, the rotation of the drum and the force of the
backwash water can be used to make the microporous screen clean in time, so that the device can always maintain a good working
condition.

Advantages

1, the equipment head loss is small, energy-saving and efficient.
2, compact structure, small occupied space.
3, automatic backwash device, stable operation, easy management.
4, seawater factory farming special microfiltration machine.
5. Application of 316L stainless steel and advanced corrosion-resistant materials to enhance seawater corrosion resistance.

Size Information

Model	RBWL1	RBWL2	RBWL3	RBWL4	RBWL5	RBWL6
Capacity(m3/h)	50-100	80-150	100-200	120-240	150-300	250-500
Filter surface(m2)	5	7	9	11	14	20
Mesh	60-250
Power(kw)	1.1	1.1	1.5	2.2	3	4

online support/we can provide engineer to help you to install it, but some costs that are incurred during business trip should be reimbursed by customers.
