Compact Aeration System For Wastewater Treatment Plant 500L/Hour

Ask Lasest Price
Brand Name :	BETTER
Certification :	ISO
Price :	$5,600.00/sets 1-2 sets

Add to Cart

Product Details
Company Profile

Compact Aeration System For Wastewater Treatment Plant 500L/Hour

Product Description

Item			WSZ-5	WSZ-10	WSZ-15	WSZ-20	WSZ-40	WSZ-50
Treating capacity m3/h			5	10	15	20	40	50
No. of machine parts			1	2	2	2	4	4
Sludge absorption and primary sedimentation tank			9	18	27	36	82	100
contact oxidation pond (m3)			24	44	63	83	170	200
Surface load of secondary sedimentation tank (m3/m2h)			1.3	1.2	1.2	1.5	1.5	1.6
Disinfection tank (m3)			2.8	5.5	8	10	20	25
Fan	Model	HC-50C	HC-60IS	HC-80S	HC-100S	HC-100S	HC-100S
		Power (kw)	1.5	2.2	3.7	5.5	5.5×2	5.5×2
		No.	2	2	2	2	3	3
Pump	Model	AS10-2CB			AS16-2CB			AS30-2CB
Pump		Power (kw)	1.0			1.6			2.9
Weight of biggest part(t)			7	8	10	10.5	10.5	12
Total weight(t)			8	17	20	21	38	42
Occupy area(m2)			20	50	65	75	155	185

WSZ is a kind of new equipment for waste water treatment by combining membrane separation technique with activated sludge method.
It can be used for municipal sewage and industrial waste water treatment .
It also can be substitute for secondary sedimentation tank in removing suspended particles, so as to increase nitrogen removal rate and organics degradation.

This machine is developed on the basis of operational experience of sewage treating device at home and broad with advanced biological treating method,while combining our own research and practice. It can remove BOD5,COD.NH3-N with stable performance and effective treating capacity, Characteristics of auto-run andnon-floor occupation saves cost and enjoys easy maintenance.Grass and flowers can be planted on the surface so the environment won't be affected. It is suitable for recovery and reuse of water from hotels, restaurants.sanitariums. hospitals, home communities. villages and towns, stations, airports.harbors, factories. mines, scenic spots, industrial organic sewage similar to municipal sewage etc and from slaughtering industry, food industry after treated. Water outlet quality meets national discharge standard and reclaimed water reuse system can be designed together with underground sewage disposal system according to client's actual needs.

Application areas:

* Domestic wastewater from distributed population such as rural areas, tourist resorts, residential areas around highways,
schools, hospitals, hotels, independent industrial and mining areas etc.
* Small amount industry wastewater which is relatively easy to treat such as sewage from hospital, pharmaceutical factory, etc.

Items	Inlet water quality(mg/l)	Outlet water standard(mg/l)
COD	<2380 - 8942	<20-60
BOD	<600-850	<50
TDS	<180 - 3330	<250
O&G	215	<10
PH		6.5-8.5

Product Advantages:

* The treated water quality could meet the strict discharge standard for municipal wastewater treatment.
* Plug & play solution, easy installation.
* The treated water could be reused for irrigation, flushing, etc.
* Short construction period with standardized production and modular configuration;
* No secondary pollution production like surplus sludge, exhaust gas and noise;
* Stable performance, easy operation, easy maintenance.
* Strong impulsion load resistance with stable operation effect.

We also strongly recommend our dencentralized undergroud small waste water treatment plant, which is modular and can be added to treat more sewage volume according to your project.
